Soffit W-Mold

Trim Purpose

Specs, MSDS, and LEED Information for Flannery Trims & Products

Flannery’s Soffit W-Molds create a transition edge where a stucco soffit meets a dissimilar wall or material. Soffit W-Molds are typically set at the corner joint where a fascia terminates and a soffit return begins.

SKU: WPM Category: Tags: ,

Product Details

Flannery’s Soffit W-Molds are standard extruded aluminum alloy 6063 T5 and have a .050” nominal wall thickness. Aluminum Plaster trims come in 10′ lengths and shall have a standard Clear Anodized Finish. Mill Finish (for field priming & painting), Chem-film finish or other factory finishes and custom paint orders are available. Click on Info Tab above for Factory Finishes.


Part No. “A” Depth “B” Width Stucco Thickness Stock Item
WPM 75-200 3/4″ 2″ 7/8″ Yes



24 Sofit W Mold Shape Dimen R1 1000 BjB - Soffit W-Mold

24 Soffit W Mold Instal Detail 1000 BjB - Soffit W-Mold
